5L 10L 12L 15L PE PP HDPE Plastic Jerry Can Extrusion Blow Molding Machinery automatic

Product Categories
Dawson Machinery & Mould Group Co.,Ltd
Trust Seal
Verified Supplier
Credit Check
Supplier Assessment
Contact Now

5L 10L 12L 15L PE PP HDPE Plastic Jerry Can Extrusion Blow Molding Machinery automatic

  • 1
  • 2
  • 3

Brand Name : Dawson

MOQ : 1

Price : USD 22800-26800

Payment Terms : L/C, T/T

Blow Molding Type : Extrusion Blow Molding Machine

Maximum Application Size : 20L

Cooling water pressure : 0.6 MPA

Water Consumption : 100 L/Min

Mould Lifespan : > 1,000,000 Cycles

Mold Material : P20, 2316, S136H, Aluminum with beryllium copper.

Language settings : Chinese, English and other language as customer need

Labor demand : 1~2 operetor

After-sales Service Provided : After-sales Service Provided

Marketing Type : Ordinary Product

Contact Now

5L 10L 12L 15L PE PP HDPE Plastic Jerry Can Extrusion Blow Molding Machinery automatic

5L 10L 12L 15L PE PP HDPE Plastic Jerry Can Extrusion Blow Molding Machinery automatic

Basic Installation Including– DSB80-30T
Die head: Center-feed die head
Extrusion system: Adopt world-famous brand automatic temperature controlling device.Drive the screw with electromagnetism motor reducer to realize step less regulating.
Clamping device: Adopt bi-directional synchronous clamping device with double axis single cylinder to stabilize equipment well
Blowing device: with upper blowing type

5L 10L 12L 15L PE PP HDPE Plastic Jerry Can Extrusion Blow Molding Machinery automatic

Basic parameters Suitablematerial PE.PP,PVC,PS,PETG,soon
Maxvolume 20L
Outputcapacity 50~60PCS/H
Size 4.8×3.4×3.6(M)
Weight 11.3T
system Specification Parameters
Extrusion system Summarize High-gradealloysteel,centerfeeding
Dieheadnumber 1
Centerdistance ofdieheads /
Maxdiemouth 200
ExtruderMotor 30kwMOTOR
